SERVER-SIDE PUSH IN SPRING BOOT AND ANGULAR

3 min readOct 21, 2022

In this tutorial, we’ll see how we can implement Server-side push-based API in spring boot.

This could be implemented using SSE (Server-sent Event), HTTP standards allow a web application to handle a unidirectional events stream and receive every event pushed by the server.

How to Implement it in Spring boot?

Step 1: We have to register subscriptions for users through which we can send events to their particular subscriptions.

List<Map<String, Object>> sseEmitterList = new CopyOnWriteArrayList<>();

We can create a list sseEmitterList to store subscriptions of multiple users.

Step 2: Now, we have to create a subscription API.

@GetMapping(value = "subscribe")
public SseEmitter subscribe(@RequestParam String userIP) {   // Create Object of SseEmitter which lives till 48 * 60 * 60000 milliseconds
   SseEmitter sseEmitter = new SseEmitter((long) (48 * 60 * 60000));
    try {
        //send init event                sseEmitter.send(SseEmitter.event().name("INIT"));
    } catch (IOException e) {
        e.printStackTrace();
    }
    Map<String, Object> userEmitter = new HashMap<>();
    userEmitter.put("ip_address", userIP);
    userEmitter.put("emitter", sseEmitter);
    sseEmitter.onCompletion(() -> this.sseEmitterList.remove(userEmitter));
    sseEmitter.onTimeout(() -> this.sseEmitterList.remove(userEmitter));   //Add emitter object to Emitter list
   this.sseEmitterList.add(userEmitter);
    return sseEmitter;
}

We can customize the duration till the subscription is valid by passing milliseconds like(48 * 60 * 60000).

Step 3: Create Post API to publish events to subscriptions.

@PostMapping("dispatch-event")
public void dispatchEventToClients(@RequestParam String ipAddress, @RequestParam String event, @RequestBody Map<String, Object> reqbody) {//iterate emitterList here
    for (Map<String, Object> sseEmitter : this.sseEmitterList) {
        try {
            if (sseEmitter.get("ip_address").equals(ipAddress)) {
             //Get required emitter according to IP Address                SseEmitter emitter = (SseEmitter) sseEmitter.get("emitter");
                if(emitter != null){
                  //Dispatch Event to subscription emitter.send(SseEmitter.event().name(event).data(reqbody));
                }
            }
        } catch (IOException e) {
            //Remove emitter
            this.sseEmitterList.remove(sseEmitter);
        }
    }
}

Step 4: Now to push the event to subscriptions we need to call our POST API with the required parameters.

ipAddress: The IP Address same as we use to create subscriptions for users in subscription API.

event: This is a title for the event which is pushing to subscription.

reqbody: Data which is pushed to subscription.

That’s all for the Spring boot side.

Complete Code…

public class UserSubscriptionController {

    List<Map<String, Object>> sseEmitterList = new CopyOnWriteArrayList<>();

    @GetMapping(value = "subscribe")
    public SseEmitter subscribe(@RequestParam String userIP) {
        SseEmitter sseEmitter = new SseEmitter((long) (48 * 60 * 60000));
        try {
            sseEmitter.send(SseEmitter.event().name("INIT"));
        } catch (IOException e) {
            e.printStackTrace();
        }
        Map<String, Object> userEmitter = new HashMap<>();
        userEmitter.put("ip_address", userIP);
        userEmitter.put("emitter", sseEmitter);
        sseEmitter.onCompletion(() -> this.sseEmitterList.remove(userEmitter));
        sseEmitter.onTimeout(() -> this.sseEmitterList.remove(userEmitter));
        this.sseEmitterList.add(userEmitter);
        return sseEmitter;
    }

    @PostMapping("dispatch-event")
    public void dispatchEventToClients(@RequestParam String ipAddress, @RequestParam String event, @RequestBody Map<String, Object> reqbody) {
        for (Map<String, Object> sseEmitter : this.sseEmitterList) {
            try {
                if (sseEmitter.get("ip_address").equals(userId)) {
                    SseEmitter emitter = (SseEmitter) sseEmitter.get("emitter");
                    if(emitter != null){
                        emitter.send(SseEmitter.event().name(event).data(reqbody));
                    }
                }
            } catch (IOException e) {
                this.sseEmitterList.remove(sseEmitter);
            }
        }
    }
}

How to use a subscription in Angular?

Step 1: Create a new subscription using IP Address and Subscription API.

this.eventSource = new EventSource(
        environment.apiUrl +
        '/subscribe?&userIP=' + this.ipAddress
);

Step 2: Use this.eventSource Object to catch all pushed events.

this.eventSource.addEventListener(event_title_to_listen,(e) => {
    console.log(e);
});

Now, you will get all server-side pushed events in your console.

Complete Code…

import { Component } from '@angular/core';@Component({
        selector: 'app-main-container',
        templateUrl: './main-container.component.html',
        styleUrls: ['./main-container.component.scss'],
})
export class MainContainerComponent {
    eventSource: EventSource;

    constructor(
    ) {
       this.createSubscription()
    }

    createSubscription(){
        this.eventSource = new EventSource(
            environment.apiUrl +
            '/subscribe?&userIP=' + this.ipAddress
         );       this.subscribeEvents();
    }

    subscribeEvents(){
      this.eventSource.addEventListener(event_title_to_listen, (e)=>
        {
         console.log(e);
     });
    }
}
